OEM/ODM
Warranty:3years
Voltage:12V
Weight:31KG
Dimensions:L407*W172*H240mm
Color:White or customization
Maintenance Type:free
Application:Communication, Traffic, IT, Financial, UPS, Solar, Radio, Electric
Power, Data Centre, Aviation, Home, Electrocar, etc
Certification:CE / UL / ISO9001 / Rohs
5.12KWH 48V lifepo4 Rack Mounted battery module.
12V 150AH Lifepo4 Lithium Battery Pack for RVs, Caravans, Motorhomes
Lifepo4 Lithium Battery Factory 12V 24V 48V 96V from 7AH to 1000AH
12V 300AH Lifepo4 Battery Pack more than 3500 Cycles High Capacity Long Life Lithium ion
Lead Acid Battery 12V 250Ah Custom LOGO Deep Cycle Battery
Parameter:
Nominal Voltage |
12V |
|
Nominal Capacity(10HR) |
100AH |
|
Dimension |
Length |
407±3mm |
Width |
173±2mm |
|
Container Height |
240±2mm |
|
Total Height (with Terminal) |
250±2mm |
|
Approx Weight |
Approx 29.5Kg (64.9 Ibs) |
|
Terminal |
T11 |
|
Container Material |
ABS |
|
Rated Capacity |
20hr ,1.80V/cell,25℃/77℉ |
110.0 AH/5.50A |
10hr,1.80V/cell,25℃/77℉ |
100.0 AH/10.0A |
|
5hr,1.75V/cell,25℃/77℉ |
87.2 A H/17.4A |
|
3hr,1.75V/cell,25℃/77℉ |
79.4 AH/26.5A |
|
1hr,1.60V/cell,25℃/77℉ |
61.1 AH/61.1A |
Feature:
1. High-strength ABS plastic battery slot and cover, compact structure. good resistance.
2. Special lead-based multi-alloy grid, with small internal resistance and corrosion resistance.
3. good opacity, strong charge acceptance.
4. New electrode plate manufacturing process, high utilization rate of active materials.
5. Multi-layer sealing technology and special sealing glue ensure that the battery has no leakage, no acid mist .
