12V 150AH Lifepo4 Lithium Battery Pack for RVs, Caravans, Motorhomes

Basic Electrical Specification

Nominal Voltage 12.8 V
Nominal Capacity 150 Ah
Energy 1920 Wh
Resistance ≤0.5mΩ
Efficiency 99%
Self Discharge ≤3% per month

Charge Specification

Recommended Charge Current 25A - (Range: 0.2C-0.5C)
Maximum Charge Current 100 A (1C)
Recommended Charge Voltage 14.6 V
BMS Charge Voltage Cut-Off 14.8 V (3.9 ±0.025 vpc) (1.1 ±0.4 s)
Reconnect Voltage 14.2 V (3.8 ±0.05 vpc)
Balancing Voltage 13.62 V (3.6 ±0.025 vpc)

Discharge Specification

Maximum Continuous Discharge Current 100A (150A BMS)
Peak Discharge Current 250A(3-5s)
BMS Discharge Current Cut-Off 450A(300ms)
Recommended Low Voltage Disconnect 10.5 V
BMS Discharge Voltage Cut-Off 9.4 V (2.0 ±0.08 vpc) (140 ±60 ms)
Reconnect Voltage 10.2 V (2.3 ±0.1 vpc)
Short Circuit Protection 200-300 µs

Temperature Specification

Discharge Temperature -4 to 130 ºF (-20 to 55 ºC)
Charge Temperature 32 to 130 ºF (0 to 55 ºC)
Storage Temperature - 1 month -4 to 113 ºF (-20 to 45 ºC)
Storage Temperature - 1 year 32 to 95 ºF (0 to 35 ºC)
BMS High Temperature Cut-Off 176 ºF (80 ºC)
Reconnect Temperature 122 ºF (50 ºC)
BMS Low Temperature Cut-Off (Charging) 32 ºF (0 ºC)
Reconnect Temperature (Charging) 41 ºF (5 ºC)

BMS Overview

Over Current Protection yes
Under Voltage Protection yes
Over Voltage Protection yes
Overload Protection yes
High Temperature Protection yes
Low Temperature Protection 32 ºF (0 ºC) / 41 ºF (5 ºC)
Short Circuit Protection yes

Mechanical Specifications

Dimensions (L x W x H) 12.80 x 6.70 x 8.66” (325*170*220mm)
Weight 30.84lbs (14kg)
Terminal Type M8 (20mm)
Terminal Torque 10 ~12 N-m
Case Material ABS
Enclosure Protection IP65
Cell Type - Chemistry Prismatic - LiFePO4

Certifications

MSDS Datasheet MSDS
UN38.3 DG61
CE Certification EN61000-6-1, EN61000-6-3
ROHS Certification ROHS
FCC Certification Part15B
IEC62619 documentation or 49 CFR IEC62619 / 49 CFR 173.185
IMDG Code UN3840 / Class 9

Cells / Internal Arrangment

Brand EVE Energy Co., Ltd
Product Prismatic Aluminum-clad LFP Battery
Model LF105
Specification 3.2 V / 50 Ah
Cell / BMS Impact Protection Large Foam Inserts as shown
Cable Size All cable sizes capable of meeting all specs set forth by BMS
Cable Color Color coded (Red/Black/Blue)
Low Temperature Probe Probe placed on cells / wire attached to BMS

BMS

Model 3SABM0-H02 (LFP-4S-100A)
Maximum Continous Discharge Current 100A (BMS support Max continous current 100A )
Cell Balancing 3.4V (13.6V)
Over Current Protection yes
Under Voltage Protection yes
Over Voltage Protection yes
Overload Protection yes
High Temperature Protection yes
Low Temperature Protection 0C Disconnect, 5C Reconnect
Short Circuit Protection yes

Battery Case

Dimensions (L x W x H) 12.80 x 6.70 x 8.66” (325*170*220mm)
Terminal Type M8 (20mm)
Terminal Torque 10 ~12 N-m
Case Material ABS
Enclosure Protection IP65

Packaging

Dimensions (L x W x H) 24.21 x 12.60 x 12.99" (615*320*330mm)
Weight 35.24 lbs (16 kg)

Packaging&shipping

Packing

Carton + Wooden + Pallet

Shipping

Express | By air | By sea
